Engine model   DEUTZ (BF4M1013EC) 115kw

Operating weight    13500kg

Rated load capacity    4000kg

Bucket capacity   2.0cbm

Model   ST20

Brand   MOONSUN

MAIN SPECIFICATION

Operating weight    13500kg

Rated load capacity    4000kg

Bucket capacity   2.0cbm

Overall dimensions(LxWxH)   7000x1800x2080mm

Max lift height   3975mm

Max dump height   1740mm

Ground clearance   250mm

Turning radius   2600mm/4900mm

Max traveling speed   8km/h

Boom raising time   ≤6.3s

Boom lowering time   ≤3.6s

Dumping time   ≤4.0s

Travel speed   0-18.0km/h

Transmission type   Hydraulic Germany DANA

Pump   USA PERMCO

Motor   SAUER MV23

Valve   USA PARKER

Working Voltage   24V

Battery   12V*2

Max breakout force   85Kn

Max traction force   104Kn

Gradeability   20°

Tire size   12.00-24 PR16 L-4S

Hydraulic oil tank capacity   120L

ENGINE

Engine model   DEUTZ (BF4M1013EC)

Engine power   115kw

Engine rated speed   2200r/min

Engine type   In-line water-cooling 4-stroke 4 cylinder direct-injection

Fuel oil tank capacity   150L

Start type   Electric
