This excavator is designed for small project garden farmland municipal works etc also can be used in playground public park. It is with small engine simple design easy to maintain.

Use the EURO5 KOOP/CHANGCHAI engine920kg.0.25 bucketwith swing boom and extended tracksUSA EATON travel motor and swing motor BEIFANG pump and valve

SPECIFICATION

Model   MN08

Brand   MOONSUN

Operating weight    850kg

Overall dimension( LxWxH)   2770x896x1490 mm

Digging bucket capacity    0.025cbm

Digging bucket width   400mm width

Engine   KOOP(KD192)

Engine power   7.6kw

Engine type   Diesel one cylinder fan cool

Egnine displacement   0.499L

Electric voltage   12V

Electric power   5W

Hydraulic main pump   SHUNSHENG

Hydraulic system pressure    16L/min

Hydraulic system flow    16Mpa

Valve   BEIFANG

Swing motor   USA EATON

Swing speed    10r/min

Traveling motor   USA EATON

Traveling speed    2.0km/h

Sealing parts   USA PARKER

Arm digging force   5.2Kn

Bucket digging force   9.5Kn

Grade ability    30 Degree

Hydraulic oil tank capacity   16.5L

Engine oil tank capacity   2.8(1.3)L

Diesel tank capacity   7L

Max. Digging height   2610 mm

Max. Dumping height   1850 mm

Max. Digging depth   1650 mm

Max. Vertical digging depth   1375 mm

Max. Digging radius   2850 mm

Min. Turning radius   1330 mm

Ground clearance   380mm

Track length   1780 mm

Track width   180 mm
