13ton CUMMINS or YUCHAI engine 92kw 0.55m3 bucket Japan Kawasaki pump and valve Italy JINGKEN swing motor Liufeng 16ton axle English monitor Radio USB all LED light Overall dimension: 7350x2520x3005mm

Model   MN130

Brand   MOONSUN

Operating weight    13T

Overall dimension   7350x2520x3005mm

Bucket capacity    0.55cbm

Engine    CUMMINS (4BT125) / YUCHAI (YC4A125)

Engine rated power/speed    92kw/2200 rpm

Engine type   Diesel4 cylinders in line

Displacement   4.075L

Voltage of start motor   12V

Starting type   ELECTRIC

Hydraulic main pump   Japan Kawasaki

Hydraulic system pressure    34.3MPa

Hydraulic system flow    2x130L/Min

Valve   Japan Kawasaki

Swing motor &  nbsp Italy JINGKEN

Swing speed 13.5r/min

Axle and Transmission   LIUFENG 4WD

Travel speed    F:1 2 3 4 51-30km/h ; R:11-15km/h

Sealing parts   USA PARKER

Bucket digging force    85Kn

Arm digging force    53Kn

Grade ability    70 Degree

Working fuel consumption   7.3L/h

Diesel oil tank capacity   200L

Engine oil tank capacity   13L

Hydraulic oil tank capacity   225L

Cooling fluid tank capacity  25L

Boom length   4450mm

Arm length   3075mm

Platform rear turning radius    2380mm

Chassis ground clearance   260mm

Platform ground clearance   715mm

Steering width   2490mm

Wheel tread   2000mm

Wheel base   2620mm

Max Digging height    8637mm

Max Dumping height    6240mm

Max Digging depth    4360mm

Max Vertical digging depth   4120mm

Max Digging radius    7660mm

Min Turning radius   2510mm

Counter weight height   950mm

Push plate lift height   360mm

Push plate width   2288mm

Total width when outrigger out   3125mm

Standard machine with A/C   AC

Packing way   One 40 frame container load two units

Passed certificates   CE ISO

Can add accessories   narrow bucket grabber hammer auger quick hitch
