21.5ton CUMMINS (6BTAA5.9)/ISUZU(4HK1) engine 112kw/133kw South korea Parker pump Japan Kawasaki valve and swing motor Japan KYB traveling motor A/C cab Grammer seat Large color monitor Radio USB 0.95m3 bucket Overall dimension: 9560x2780x3040mm

Model   MN210

Brand   MOONSUN

Operating weight    21.5T

Overall dimension   9560x2780x3040mm

Bucket capacity    0.95cbm

Engine    CUMMINS (6BTAA5.9)/ISUZU(4HK1)

Engine rated power/speed    112kw/2100rpm/133kw/2000rpm

Engine type   Diesel 6 cylinders in line

Voltage of start motor   12V

Starting type   ELECTRIC

Hydraulic main pump   South Korea Parker

Hydraulic system pressure    34.3MPa

Hydraulic system flow    225x2L/Min

Valve   Japan Kawasaki

Swing motor   Japan Kawasaki

Swing speed    11.7r/min

Travel motor   Japan KYB

Travel speed    high 5.2km/h low 3.5/km/h

Bucket digging force    138Kn

Arm digging force    106Kn

Grade ability    70 Degree

Ground pressure   46.5KPa

Working fuel consumption   14.2L/h

Diesel oil tank capacity   350L

Engine oil tank capacity   36L

Hydraulic oil tank capacity   246L

Cooling fluid tank capacity   120L

Boom length   5700mm

Arm length   2900mm

Platform rear turning radius   2720mm

Chassis ground clearance   466mm

Platform ground clearance   1065mm

Track length on the ground   3260mm

Track length   4075mm

Track shoe width   600mm

Track shoe thickness   10mm

Steering width   2700mm

Max Digging height    9275mm

Max Dumping height    6560mm

Max Digging depth    6515mm

Max Vertical digging depth   5915mm

Max Digging radius    9865mm

Min Turning radius   3650mm

Counter weight height   2120mm

Standard machine with A/C   AC

Packing way   One 40 frame container load one unit

Passed certificates   CE ISO

Can add accessories   quick hitch hammer
