Operating weight   790kg Vibrating drum   Double steel wheel Static linear load   55N/cm Vibrating frequency   65Hz Amplitude   0.5mm Centrifugal force   20Kn Engine   HONDA (GX390)/Gasoline;  CHANGCHAI (178F)/Diesel

Operating weight   790kg Vibrating drum   Double steel wheel Static linear load   55N/cm Vibrating frequency   65Hz Amplitude   0.5mm Centrifugal force   20Kn Engine   HONDA (GX390)/Gasoline;  CHANGCHAI (178F)/Diesel Engine cylinder   One Engine power   9.7kw /6.0kw Engine rated speed   3600r/min Voltage   12V Wheel base   650mm Vibrating drum   Front+Back Drive way   Stepless speed change two wheels drive motor Mechanical Steering way   Hydraulic Steering system   Swing articulated Travel speed   0-5.0km/h Grade ability   30% Working width   680mm Drum width   620mm Drum diameter   355mm Total length   2500mm/1800mm Total height with ROPS   1140mm/1710mm Turning radius（Outer）   2300mm Start way   Electric Driving way   Hydraulicchain drive Type of sprinkling   Gravity spray Fuel capacity   6.5L /5.5L Hydraulic oil capacity   28L/ 28L Water capacity   30L/ 30L
