Operating weight:3100kg

Rated loading capacity:1000kg

Bukcet capacity:0.5CBM

Yunnei engine 37kw

smart design

Model   MNL910

Brand   MOONSUN

MAIN SPECIFICATION

Operating weight    3100kg

Rated load capacity    1000kg

Bucket capacity   0.5cbm

Bucket width   1300mm

Overall dimensions(L×W×H)   4830×1500×2580mm

Wheel base   1850mm

Dumping height   2550mm

Dumping reach   700mm

Tire size   8.25-16

Max traveling speed   25km/h

OPERATION SPECIFICATION

Breakout force   20Kn

Hydraulic system pressure setting   16Mpa

Hydraulic flow   63L/min

Hydraulic cycle times   <9S

Steering angle left/right   36°

Minimum turning radius over bucket   3600mm

Transmission type   Mechanical Pilot

Transmission gears   F3/R2

Axle brand   ISUZU 130

Service brake   Oil brake

Parking brake   Drum

ENGINE

Engine model   YUNNEI (490)

Engine power   37kw

Engine rated speed   2200r/min

Engine type   In-linewater-cooling4-stroke4 cylinderdirect-injection

Start type   Electric
