Operating weight:7200kg

Rated loading capacity:3000kg

Bukcet capacity:1.5CBM

YTO engine 92kw

Model   MNL930

Brand   MOONSUN

MAIN SPECIFICATION

Operating weight    7200kg

Rated load capacity    3000kg

Bucket capacity   1.5cbm

Bucket width   1980mm

Overall dimensions(L×W×H)   6250×2180×2950mm

Wheel base   2450mm

Dumping height   3600mm

Dumping reach   1200mm

Tire size   17.5-25

Max traveling speed   28km/h

OPERATION SPECIFICATION

Breakout force   30Kn

Hydraulic system pressure setting   18Mpa

Hydraulic flow   90L/min

Hydraulic cycle times   <9S

Steering angle left/right   36°

Minimum turning radius over bucket   5900mm

Transmission type   Hydraulic

Transmission gears   F2/R2

Axle brand   SDLG

Service brake   Air push Oil brake

Parking brake   Disc

ENGINE

Engine model   YTO(6105 Turbo-charge)

Engine power   92kw

Engine rated speed   2200r/min

Engine type   In-linewater-cooling4-stroke4 cylinderdirect-injection

Start type   Electric
